Introduction[edit | edit source]
Prepreg materials are known for producing high performance composite materials and are considered the gold standard in many demanding applications. One of the drawbacks of prepregs is the need to process them in an autoclave, which can increase cost and complexity compared to alternative methods. To address this, ‘Out of Autoclave’ prepregs have been developed that do not require the high pressures provided by an autoclave and therefore, can be cured with alternate methods. This has the potential to reduce overall costs, however other challenges may arise.
This webinar will provide an introduction to Out-of-Autoclave prepregs in composites manufacturing. Opportunities and limitations, and a direct comparison of their performance against conventional prepreg systems will be discussed. Processing considerations, including layup, effective consolidation techniques, and advanced thermal management for curing will be explored. Case studies will be presented to illustrate these points.
Presenter[edit | edit source]
Dr. Casey Keulen
Assistant Professor of Teaching, Department of Materials Engineering, The University of British Columbia
Director, Knowledge in Practice Centre, CKN
Webinar[edit | edit source]
Webinar slides[edit | edit source]
Webinar slides available by clicking on the icon below
Additional information for select chapters[edit | edit source]
| Chapter | Chapter Title | Links to related information in the Knowledge in Practice Centre |
|---|---|---|
| 1 | Welcome & introductions | N/A |
| 2 | Knowledge in Practice Centre | |
| 3 | Outline | |
| 4 | What is OoA prepreg processing | |
| 5 | History and application of OoA | |
| 6 | Comparison of processing requirements | |
| 7 | OoA curing stages | |
| 8 | Layup process and consolidation | |
| 9 | Thermal management case study | |
| 10 | Mechanical comparison case study 1 | |
| 11 | Mechanical comparison case study 2 | |
| 12 | Summary | N/A |
| 13 | Q&A | N/A |
 |
 |
