Introduction[edit | edit source]
Effective thermal management to control cure during manufacturing of thermoset composite parts is one of the critical activities to achieve the required outcomes in terms of part quality, mechanical properties and dimensional conformity. Although the fundamental heat transfer mechanisms remain the same, different manufacturing processes and equipment have specific considerations that must be taken into account while developing the thermal transformation step.
This webinar will focus on using fundamental heat transfer concepts for three different case studies to provide insights into developing a cure process for thermoset composites. Each case study will highlight and discuss the key parameters that affect the curing part as well as how to include them in designing processes for successful curing of composite parts.
Presenter[edit | edit source]
Dr. Casey Keulen
Assistant Professor of Teaching, Department of Materials Engineering, The University of British Columbia
Director, CKN Knowledge in Practice Centre
Webinar[edit | edit source]
Webinar slides[edit | edit source]
Webinar slides available by clicking on the icon below
Additional information for select chapters[edit | edit source]
| Chapter | Chapter Title | Links to related information in the Knowledge in Practice Centre |
|---|---|---|
| 1 | Welcome & introductions | N/A |
| 2 | Knowledge in Practice Centre | |
| 3 | Outline | |
| 4 | Reviewing heat transfer in composites | |
| 5 | MSTEP approach to thermal management | |
| 6 | Equipment and process decisions | |
| 7 | CS1 - Room temperature cure | |
| 8 | CS2 - Resin transfer moulding | |
| 9 | CS3 - Oven/autoclave cure | |
| 10 | CS4 - Thermal profiling | |
| 11 | Key takeaways | N/A |
| 12 | Q&A | N/A |
 |
 |
